Portable Solar Battery System

PowerOAK Lithium Ion Battery Solar Generator

PS10B

By Jane Lu/ Jan 13^th, 2016

PS10B Features:

1. Pure sine wave inverter of PS10B, which makes PS10B great work w/ any devices and equipments

2. Portable solar generator w/ built-in li-polymear battery
3. LED lights for indicating battery status and charging status.

4. Backup power supply fo hospital, school and home when main supply fails or disaster come

5. Power for your camping, canbin, wild travel, fishery, farm

PowerOak Portable Solar Generator is a clean solar off grid system, with built in lithium ion battery pack, BMS, Pure Sine Wave Inverter, and MPPT PV charger, Smart Control system. This is complete All-in-One lithium ion battery solar generator. Your best solar back up generator for your daily using.

Front View:

The size of PowerOak Solar off-grid system PS10B is very small.

And you can handle it very easily:

Product Parameter:

Model No.	PS10B-P1			PS10B-P2
Battery
Battery Capacity	700Wh	1200Wh	1500Wh	700Wh	1200Wh	1500Wh
Battery Type	Li-ion Battery			Li-ion Battery
Battery Cell	Li-Polymer Battery			Li-Polymer Battery
Output
Rated Output Power	500W			500W
Peak Output	700W			700W
Output Voltage	100V/110V/120Vac			220V/230V/240Vac
Output Frequency	50Hz/60Hz			50Hz/60Hz
Overload Ability	120%<load<130% @10min; 130%<load<150% @10s			120%<load<130% @10min; 130%<load<150% @10s
UPS Function	No			No
On/off Grid	Off Grid			Off Grid
Max Efficiency	90%(>70% Load)			90%(>70% Load)
AC Charge
Input Voltage	88～264Vac			88～264Vac
Power Factor	≥0.94(full load)			≥0.94(full load)
Input Frequency	50/60Hz±5 Hz			50/60Hz±5 Hz
Max Charge Power	327W			327W
Max Efficiency	>92%			>92%
PV Charge
Max Input Power	210W			210W
Start-up Voltage	18Vdc			18Vdc
MPPT Amount	1			1
MPPT Input Voltage	18~50 Vdc			18~50 Vdc
Max Input Voltage	150 Vdc			150 Vdc
MPPT Efficiency	99.50%			99.50%
Max Efficiency	>95%			>95%
Solar Charing Model	MPPT			MPPT
General
Operation Environment	Relative humidity: 5%~90%
	Temperature： 0~40℃
Product Size	405×215×261mm
Packing Size	485×296×390mm
Net Weight	7.8kgs	10kgs	12kgs	7.8kgs	10kgs	12kgs
Gross Weight	9.4kgs	11.4kgs	13.6kgs	9.4kgs	11.4kgs	13.6kgs

CHARGING

THERE ARE 2 WAYS TO CHARGE YOUR POWEROAK PS10B:

The Sun

The PowerOak Solar Off Grid System can be charged by connecting a compatible solar panel or use our Solar Charging Calculator.

Wall

The POWEROAK Portable solar generator PS10B can be recharged from a regular wall outlet in 3-5 hours. You can charge your PS10B with solar panels, and a wall charger at the same time

POWERING

THE POWEROAK PS10B POWERS YOUR DEVICE IN 2 WAYS:

12V

The 12V best charges all your 12V powered devices.

AC Inverter

Plug in your device just as you would the wall. There are three AC Outlets (pure-sine wave)

WHAT TO POWER FROM THE PowerOak Lithium Ion Battery Solar Generator PS10B:

1. Office Equipment:

PC, telephone, printer, display device, copy machine, fax machine, paper shredder, projector

2. Home Device:

TV, video recorder, sounding device, DV/VCD display monitors, fan, lighting, and refrigerator

3. Travel use:

Camping, Led lighting, microwave oven, cooking

4. Outdoor use:

Power tool, cabin, rescue and relief work, adervising board, commercial and social activities, outdoor film and television shooting filed, farm, fishery.

5. Life use:

Mobile phone, tablets, PDA, digital video recorder, digital camera, battery charge, GPS

HOW LONG WILL IT TAKE TO CHARGE YOUR DEVICE FROM POWEROAK POWER PACKS?

It takes the same amount of time to charge your device from a Goal Zero power pack as it does from the wall.

How to calculate PS10B discharge time?

Capacity of PS10B(700Wh/1100Wh/1500Wh) ÷ power of load (W) = Discharge Time (H)

STORAGE AND DOWNTIME MAINTENANCE

Fully charge your PS10B every 3 months and store in a cool, dry place. Failure to maintain the PS10B by following this step can result in battery damage which will void the product warranty.

WHAT IS THE WARRANTY

The standard warranty time of the PS10B is 2 years. For more warranty time, it could be negotiable.

SHENZHEN POWEROAK NEWENER Co., Ltd

Add: West 11-13th floor, A2 building, Zhongtai Infomation Technology industrial park, Dezheng Road, Shiyan Street, Baoan District, Shenzhen, China

Mobile: 0086-18617002248

Tel: 0086-755-23705980 ext. 8078

Skype/Yahoo: Jane_Lu20111024

Website: www.kayomaxtar.com; www.poweroak.net

Email: jane@kayomaxtar.com

Portable Solar Power Generator for Homes

PS5B

By Jane Lu/ Jan 8^th, 2016

PowerOak Portable Solar Power Genertor for homes-PS5B is PowerOak new product at the end of 2015.

What are the specials of PS5B? Why it will become more and more popular in solar backup generator market? Why it will become a necessary portable solar power generator for homes?

Portable Solar Power Genertor for homes - PS5B

PS5B is a very small portable solar generator for homes, RVs, camping. It is only 6.5kgs, but with 300W output power, 400Wh capacity. It can be a very good solar backup generator for your refrigerators, and laptops, projectors.

PS5B Features:

1. Quiet, portable power for base camp, cabins and unexpected outages

2. Portable Wall Outlet: Powers laptops, LED lights and smartphones anywhere

3. Easy to Carry: Convenient pop-up handle, only 5.6kgs/12.32Ibs

4. Charging Flexibility: Refuel from wall, car or sun

5. Compatible Solar Panels: Escape 30, Boulder 15, Nomad 27, Nomad 13.

Product Parameter

POWERING

THE PowerOak portable solar generator PS5B POWERS YOUR DEVICE IN 3 WAYS:
USB

The USB port best charges all your medium size USB powered devices.

12V

The 12V best charges all your medium 12V powered devices

AC Inverter

Plug in your device just as you would the wall.

WHAT TO POWER FROM THE POWEROAK portable solar power system PS5B:

Smartphones, MP3 Players, Digital Cameras, E-readers, tablets, Led Lights, Car Adapters, Laptops, DSLR Cameras, CPAP, Display Monitors, etc.

For your home: TV, small refrigerator, hot plate, projector.

HOW LONG WILL IT TAKE TO CHARGE YOUR DEVICE FROM POWER PACKS?

It takes the same amount of time to charge your device from PS5B power pack as it does from the wall.

WHAT PRODUCTS ARE NOT SUITABLE TO USE WITH YOUR solar backup generator PS5B

Pure sine wave inverter, used in the PS10B is the best inverter compared market modified sine wave inverter. Pure sine wave inverter can drive any common devices which can access to electricity. Compared to modified sine wave inverter, which has much restrictions of the load, such as capacitance load (take rechargeable LED flashlight for example) will appear the impact of current at the edge of the pulse, resulting in capacitance load easily be damaged when in modified sine wave power; and in inductance class load (such as Electric motor machines) work, it will also appear abnormal.

But Pure Sine Wave inverter is great with any electronic equipment. No matter resistive load(such as rechargeable LED torch), capacitance load, or inductance load, anything that includes an AC power cable with the box, like you TV, laptop, which can be perfectly used with no damage.

Compared to modified sine wave inverter, pure sine wave inverter is suitable for any devices, no limitation. PS5B can work with follow devices, which modified sine wave inverter can't work with: Fluorescent lights with dimming function, Power tools in variable speed control, digital clocks with radios, and sewing machines with speed control.

WHAT IS THE WARRANTY

The standard warranty time of the Solar Power Generator PS5B is 2 years. For more warranty time, it could be negotiable.
